EVE SPI TFT Series Displays

Posted by Ian 25/08/2017 0 Comment(s) Press Releases,



Matrix Orbital is pleased to announce the addition of EVE2 SPI TFT’s to our display line. These displays utilize FTDI’s second generation Embedded Video Engine to control, render, manage and display complex graphics on a full color SPI TFT touch screen. Using the SPI communication protocol provides application flexibility with a wide range of compatible microcontrollers – including FTDI FT900, NXP 17XX, Arduino and many more. With the built in graphics operations, sound synthesizer, digital filter and support for multiple widgets you can create your own stunning screens and interfaces with the EVE Screen Designer software.

  • Six sizes available:
    • 2.9” (320 x 102), 1U Form Factor
    • 3.5” (320 x 240)
    • 3.8” (480 x 116), 1U Form Factor
    • 4.3” (480 x 272)
    • 5.0” (800 x 480)
    • 7.0” (800 x 480)
  • Available with Touch or Non-Touch
  • FT812 CPU
  • 1 MB graphics RAM
  • Backlight PWM LED Driver
  • Standard 20 Pin Connector
  • Mono 8-bit linear audio wave playback
  • SPI and QSPI communication protocol
  • Advanced Embedded Video Engine (EVE) with high resolution graphics and video playback
  • EVE Screen Designer (ESD) 3.x GUI drag and drop design suite
  • Supports multiple widgets
  • Supports landscape or portrait orientations
  • Supports playback of motion-JPEG encoded AVI videos
  • Extended Operating temperature range: -20oC to 70oC
